Introduction
Congratulations on your purchase of a Renkus-Heinz CF/CFX101LA series point source line array
loudspeaker system. Your CF/CFX series loudspeaker has been designed to provide you years of
trouble-free high performance listening pleasure. We hope you enjoy it.
Your CF/CFX101LA series loudspeaker was carefully tested and fully inspected before leaving our
factory and should have arrived in perfect condition. Please carefully inspect your loudspeaker and
its shipping carton for any noticeable damage and if any damage is found, immediately notify the
shipping company.
Only the consignee may institute a claim with the carrier for any damage incurred during shipping. Be
sure to save the carton and all packing materials for the carrier’s inspection.
It is also a good idea to save the carton and packing material even though the loudspeaker arrived in
good condition. If shipping the loudspeaker should ever be required, it should be shipped only in its
original factory packing.
Table of Contents
Introduction 2
Modular Point Source Line Arrays , An Overview 3
Ground Stacked & Pole Mounted Systems 4
Flying Arrays 5
Subwoofer Assembly 5
EASE Focus 6
CXF101LA Connections 6
CFX101LA-5 Connections 7
CF101LA-5R & CF101LA-52R Connections 8
High Frequency Control Settings 9
CFX101LA & CFX15S DSP Settings 10
Technical Specifications 12
Technical Support
If you run into any problems or have any questions about these products, please call our
technical support staff at +1 949 588 9997 and ask the operator for technical support
Call Monday through Friday from 8:30 AM to 5:00 PM Pacific time.
