- 3 -
CHECKLIST
Your product may vary slightly from the picture above.
Item Description Qty Item Description Qty
Pump 1 Anti-vibration feet 3
Chip Foam Pad 1
A B
C
Fig. 1
28 mm copper
inlet pipework
(suction).
28 mm isolating valve
(non restrictive) and
fittings
(not supplied)
must be fitted to allow
easy pump service.
28 mm copper outlet
pipework (discharge).
Short 28 mm copper pipe
tails to connect between
isolating valve and flexible
pipes.
28 mm isolating valve
(non restrictive) and
fittings
(not supplied)
to allow easy pump
service.
28 mm - G 1 connector
(not supplied) must
be fitted
A
IMPORTANT: With the pump
removed from its packaging check
for any damage prior to installation.
If any damage is found contact Stuart
Turner Ltd within 24 hours of receipt.
PH TS FL
PHD FL
PH ES FL
KFL
B
C
