7 technical specification – Stuart Turner PH 35 TS FL User Manual
Page 15
- 15 -
7 TECHNICAL
SPECIFICATION
Stuart Turner reserve the right to amend the specification in line with its policy of
continuous development of its products.
*Note: Max working pressure is the maximum pressure that can be applied to
the pump internal casing under any installation conditions.
**Note: In normal circumstances the temperature of stored water should never
exceed 65 °C. A stored water temperature of 60°C is considered
sufficient to meet all normal requirements and will minimise deposition of
scale in hard water areas.
7.11
Noise: The equivalent continuous A-weighted sound pressure level at a distance
of 1 metre from the pump does not exceed 70 dB(A).
Model
PH 35
TS FL
PH 45
TS FL
PHD 35
FL
PHD 45
FL
PH 35
ES FL
PH 45
ES FL
KFL
9-2
KFL
12-2
Electrical
Power supply
Volts/phase frequency
230/1/50
230/1/50
230/1/50
230/1/50
230/1/50
230/1/50
230/1/50
230/1/50
Enclosure
IPX4
IPX4
IPX4
IPX4
IPX4
IPX4
IPX4
IPX4
Type of motor
Induction
Induction
Induction
Induction
Induction
Induction
Induction
Induction
Power consumption
295 Watts
420 Watts
640 Watts
855 Watts
320 Watts
405 Watts
265 Watts
485 Watts
Full load current
1.3 Amps
1.9 Amps
2.9 Amps
3.7 Amps
1.4 Amps
1.8 Amps
1.2 Amps
2.1 Amps
Rating
Continuous (S1) @ 2.5 l/min & above
Continuous (S1) @
4.5 l/min & above
Continuous (S1)
Max. No Starts per hour
60
60
60
60
60
60
60
60
Mechanical
Min inlet head
1 metres
1 metres
1 metres
1 metres
1 metres
1 metres
1 metres
1 metres
Max inlet head
14 metres
14 metres
14 metres
14 metres
14 metres
14 metres
14 metres
14 metres
Max head (closed valve)
30 metres
40.6
metres
28.7
metres
41.6
metres
29.5
metres
40 metres
9 metres
13.9
metres
Max working pressure*
600 kPa
(6.0 bar)
600 kPa
(6.0 bar)
600 kPa
(6.0 bar)
600 kPa
(6.0 bar)
600 kPa
(6.0 bar)
600 kPa
(6.0 bar)
600 kPa
(6.0 bar)
600 kPa
(6.0 bar)
Max ambient air
temperature
40
o
C
40
o
C
40
o
C
40
o
C
40
o
C
40
o
C
40
o
C
40
o
C
Max water temperature**
80
o
C
80
o
C
80
o
C
80
o
C
80
o
C
80
o
C
65
o
C
65
o
C
Min water temperature
4
o
C
4
o
C
4
o
C
4
o
C
4
o
C
4
o
C
4
o
C
4
o
C
P
ump
Dimensions
Length (max)
201 mm
201 mm
300 mm
300 mm
232 mm
232 mm
242 mm
242 mm
Width (max)
126 mm
126 mm
126 mm
126 mm
126 mm
126 mm
133 mm
133 mm
Height (excluding flexible
hoses)
201 mm
201 mm
201 mm
201 mm
221 mm
221 mm
231 mm
231 mm
Gross Weight
4.9 Kg
5.7 Kg
7.9 Kg
8.4 Kg
5.1 Kg
6.6 Kg
6.5 Kg
6.7 Kg
Pump Connections:
Inlet
G ¾
Female
G ¾
Female
G ¾
Female
G ¾
Female
G 1
Female
G 1
Female
G 1
Female
G 1
Female
Outlet
G ¾ Male
G ¾ Male
G ¾ Male
G ¾ Male
G 1
Female
G 1
Female
G 1
Female
G 1
Female
Materials
Pump body
Brass
Brass
Brass
Brass
Brass
Brass
Brass
Brass
Shaft
St. St.
St. St.
St. St.
St. St.
St. St.
St. St.
St. St.
St. St.
Mechanical seal
Nit/car/cer
Nit/car/cer
Nit/car/cer
Nit/car/cer
Nit/car/cer
Nit/car/cer
Nit/car/cer
Nit/car/cer
