Stuart Turner Showermate S1.8 bar Twin - Manual (Page 18)

- 18 -
Cont ...
Stuart Turner reserve the right to amend the specification in line with its policy of
continuous development of its products.
Note: For information on other voltages/frequencies which are not shown, consult any
supplementary instruction sheet supplied, or the rating label attached to the
pump.
*Note: Max working pressure is the maximum pressure that can be applied to the
pump internal casing under any installation conditions.
**Note: In normal circumstances the temperature of stored water should never exceed
65°C. A stored water temperature of 60°C is considered sufficient to meet all
normal requirements and will minimize deposition of scale in hard water areas.
Maximum permissible water temperature 65°C.
7.11 Noise: The equivalent continuous A-weighted sound pressure level at a distance
of 1 metre from the pump does not exceed 70 dB(A).
7 TECHNICAL SPECIFICATION
Model S2.6 bar Single S1.8 bar Twin S2.6 bar Twin
Electrical
Power supply
Volts/phase freqency
230/1/50 230/1/50 230/1/50
Enclosure IPX4 IP22 IP22
Type of motor Induction Induction Induction
Power consumption 245 Watts 405 Watts 505 Watts
Full load current 1.1 Amps 1.8 Amps 2.2 Amps
Rating
Int (S3) 30 mins on/30
mins off @ 9 l/min
Int (S3) 30 mins on/30
mins off @ 9 l/min
(Both ends pumping) Int (S3) 30 mins on/30
mins off @ 9 l/min
(Both ends pumping)
Max. No Starts per hour 60 60 60
Mechanical
Max inlet head 13 metres 13 metres 13 metres
Max head (closed valve) 26 metres 18 metres 26 metres
Max working pressure* 380 kPa (3.8 bar) 380 kPa (3.8 bar) 380 kPa (3.8 bar)
Max ambient air temperature 40 o C 40 o C 40 o C
Max water temperature** 65 o C 65 o C 65 o C
Min water temperature 4 o C 4 o C 4 o C
P
ump
Dimensions
Length 223 mm 304 mm 319 mm
Width 132 mm 132 mm 132 mm
Height (excluding flexible hoses) 179 mm 179 mm 179 mm
Weight (excluding flexible hoses) 4.2 Kg 4.9 Kg 5.8 Kg
Pump Connections: Inlet G ¾ Male G ¾ Male G ¾ Male
Outlet G ¾ Male G ¾ Male G ¾ Male
