- 15 -

Cont ...

7 TECHNICAL

SPECIFICATION

Stuart Turner reserve the right to amend the specification in line with its policy of
continuous development of its products.

*Note: Max working pressure is the maximum pressure that can be applied to

the pump internal casing under any installation conditions.

**Note: In normal circumstances the temperature of stored water should never

exceed 65 °C. A stored water temperature of 60°C is considered

sufficient to meet all normal requirements and will minimise deposition of

scale in hard water areas.

7.11

Noise: The equivalent continuous A-weighted sound pressure level at a distance

of 1 metre from the pump does not exceed 70 dB(A).

Model

U1.4 bar

U2.6 bar

U3.6 bar

U5.0 bar

Electrical

Power supply
Volts/phase frequency

230/1/50

230/1/50

230/1/50

230/1/50

Enclosure

IPX4

IPX5

IPX5

IPX5

Type of motor

Induction

Induction

Induction

Induction

Power consumption

415 Watts

775 Watts

1136 Watts

1630 Watts

Full load current

1.8 Amps

3.5 Amps

5.1 Amps

7.3 Amps

Rating

Continuous (S1)

Continuous (S1)

Continuous (S1)

Continuous (S1)

Max. No Starts per hour

60

60

60

60

Mechanical

Min inlet head

1 metres

1 metres

1 metres

1 metres

Max inlet head

8 metres

10 metres

10 metres

10 metres

Max head (closed valve)

14 metres

26 metres

36 metres

50 metres

Max working pressure*

500 kPa (5.0 bar)

600 kPa (6.0 bar)

900 kPa (9.0 bar)

900 kPa (9.0 bar)

Max ambient air temperature

40

o

C

40

o

C

40

o

C

40

o

C

Max water temperature**

65

o

C

65

o

C

65

o

C

65

o

C

Min water temperature

4

o

C

4

o

C

4

o

C

4

o

C

Cut out flow

1 l/min (approx)

1 l/min (approx)

1 l/min (approx)

1 l/min (approx)

Cut in pressure

80 kPa (0.8 bar)

180 kPa (1.8 bar)

180 kPa (1.8 bar)

180 kPa (1.8 bar)

Vessel pre-charge

90 kPa (0.9 bar)

210 kPa (2.1 bar)

210 kPa (2.1 bar)

210 kPa (2.1 bar)

P

ump

Dimensions

Length (max)

273 mm

394 mm

418 mm

469 mm

Width (max)

159 mm

155 mm

155 mm

187 mm

Height (excluding flexible hoses)

333 mm

308 mm

308 mm

327 mm

Gross Weight (including accessories)

8.5 Kg

12.4 Kg

14.4 Kg

18.4 Kg

Pump Connections: Inlet

G 1 Male

G 1 Male

G 1 Male

G 1 Male

Outlet

G 1 Male

G 1 Male

G 1 Male

G 1 Male
