Appendix - 65 -
English
Figure 1
In the SATAII RAID Config submenu, enable SATA-II RAID function. Then enable the SATA ports
with hard disks that you want to use for RAID. In the example in Figure 2, enable SATA-II 1 Primary/
Secondary RAID). (For example, if you wish to create RAID with hard disks on the SATAII0 and
SATAII1 connectors, set SATA-II 1 Primary/Secondary RAID to Enabled).
Figure 2
The BIOS Setup menus described in this section may not show the exact settings for your
motherboard. The actual BIOS Setup menu options you will see shall depend on the motherboard
you have and the BIOS version.
CMOS Setup Utility-Copyright (C) 1984-2005 Award Software
Integrated Peripherals
SATAII RAID Config [Press Enter]
On-Chip IDE Channel0 [Enabled]
On-Chip IDE Channel1 [Enabled]
IDE1 Conductor Cable [Auto]
IDE2 Conductor Cable [Auto]
Serial-ATA-II 1 [Enabled]
On-Chip USB [V1.1+V2.0]
USB Keyboard Support [Disabled]
USB Mouse Support [Disabled]
Onboard Audio Function [Auto]
Onboard LAN Function [Auto]
Onboard LAN Boot ROM [Disabled]
Onboard 1394 Function [Enabled]
Onboard Serial Port 1 [3F8/IRQ4]
Onboard Serial Port 2 [2F8/IRQ3]
Onboard Parallel Port [378/IRQ7]
Parallel Port Mode [SPP]
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F7: Optimized Defaults
Item Help
Menu Level
CMOS Setup Utility-Copyright (C) 1984-2005 Award Software
SATAII RAID Config
Item Help
Menu Level SATA-II RAID function [Disabled]
x SATA-II 1 Primary RAID Disabled
x SATA-II 1 Secondary RAID Disabled
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
