Hardware Installation - 17 -
English
1-7 Connectors Introduction
You can use audio software to configure 2-/4-/6-/8-channel audio functioning.
1) ATX_12V
2) ATX (Power Connector)
3) CPU_FAN
4) SYS_FAN
5) FDD
6) IDE1 / IDE2
7) SATAII0
8) F_PANEL
Center/Subwoofer Speaker Out
Connect the Center/Subwoofer speakers to this connector.
Rear Speaker Out
Connect the rear surround speakers to this connector.
Side Speaker Out
Connect the side surround speakers to this connector.
9) F_AUDIO
10) CD_IN
11) F_USB1 / F_USB2
12) POWER_LED
13) CI
14) CLR_CMOS
15) BATTERY
16) F1_1394
17) SPDIF_IO
1 2
3
5
4
6
7
8
9
10
11
13
15 14 12 16
17
