How to order Replacement Parts
Please provide the following information to your local representative:
• Model Number
• Serial Number (if any)
• Part Description and Number as shown in Replacement Parts Literature
If further assistance is needed, please contact the manufacturer's customer service department.
1, 2 - Unit Type [UT]
EV - Evaporative Cooler Only
3, 4 - Capacity [CA]
10 - 100,000 BTU/HR
15 - 150,000 BTU/HR
20 - 200,000 BTU/HR
25 - 250,000 BTU/HR
30 - 300,000 BTU/HR
35 - 350,000 BTU/HR
40 - 400,000 BTU/HR
5 - Furnace Type [FT]
0 - None
6 - Furnace Construction Material [FM]
0 - None
7 - Rooftop Arrangement [RA]
0 - None
8 - Coil Options [CO]
0 - None
9 - Gas Type [GT]
0 - None
10 - Gas Control [GC]
0 - None
11 - Supply Voltage [SV]
1 - 115/1/60
2 - 208/1/60
3 - 230/1/60
12 - Motor Type [MT]
0 - None
13 - Motor Sizes [MS]
0 - None
Digit E X X — E V 3* 4* 0 0 0 0 0 0 11* 0 0 0 0 16* 17* +
Item Prefi x UT CA FT FM RA CO GT GC SV MT MS AI AC AS
(Internal use Only)
14 - Air Inlet Confi guration [AI]
0 - None
15 - Air Control & Damper Arrangement [AC]
0 - None
16 - Accessories [AS]
C1 - Evap. Cooler - Fill & Drain Kit
C2 - Evap. Cooler - 12" Celdek ® Media
C3 - Evap. Cooler - Freezestat
D1 - Time Clock - 7 Day
D2 - Time Clock - 24 Hour
E2 - G.F.I. Convenience Outlet 115VAC
E3 - Remote Control Panel
F1 - Ductstat - One Stage
F2 - Ductstat - Two Stage
G1 - Thermostat - T87F w/Subbase
G2 - Thermostat - T87F w/Subbase & Guard
G3 - Thermostat - T834H w/Subbase (Sterling Stat)
G4 - Thermostat - T7300 - 7 Day Programmable
G5 - Thermostat - T874 (Two Stage)
H1 - Return Firestat
H2 - Supply Firestat
H3 - Freezestat
L1 - 30 Amp, Fused Disconnect Switch
L2 - 30 Amp, Non Fused Disconnect Switch
L3 - 60 Amp, Fused Disconnect Switch
L4 - 60 Amp, Non Fused Disconnect Switch
0 - Other (Specify)
*See Model No. Description below.
Evaporative Cooler Model Number Description
LIMITED WARRANTY
The complete unit is warranted by the manufacturer to be free from defects in material and workmanship for a
period of one (1) year from the date of manufacture.
The manufacturer will repair or replace, at its option, any component which, upon inspection, it fi nds to be
defective, provided that the unit has been operated within its listed capacity, has been installed in accordance with
the furnished instructions, has not been misused or subjected to negligence and has received reasonable and
necessary maintenance. The warranty does not cover labor costs or other costs incurred in repairing, removing,
installing, servicing or handling of parts or completed products.
The warranty does not cover loss due to corrosion by chemicals precipitated in the air such as halogenated
hydrocarbons. The manufacture will in no event be liable for incidental or consequential damages of any kind
whatsoever.
Written permission is required prior to the return of defective components. All returns must be sent with all
transportation charges prepaid to the plant designated in the written permission.
This warranty is extended only to the original owner of the unit.
