<3. Procedures for Setting PR300 Functions>
IM 77C01E01-10E
3.5.3 Parity
[Procedure]
(1) To set the parity, write data to the D register in the table below. The data type is integer.
(2) After writing that value, write 1 to the RS-485 writing status register, D0277.
D Register
D0273
D0277
Reference No.
40273
40277
H No.
0110
0114
Description
Parity
RS-485 writing status
(D0271 to D0276 are
validated)
Effective Range
0: NONE
1: EVEN
2: ODD
If other than 1: Invalid
If 1: Writing is executed
Initial value of parity: 0 (NONE)
[Example]
To set the parity to 1 (EVEN):
For station number 01, use PC link communication (without checksum) and the random
write command as shown below:
[Command]
[STX]01010WRW02D0273,0001,D0277,0001[ETX][CR]
[Response]
[STX]0101OK[ETX][CR]
