8.10 Ordering structure RF20H (Extract 810 and 820) S.S./Hast.
RF20H (Extract 810 and 820)
RF20H pH-Retractable Holder RF20H remark
Material (wetted parts) -PP PP Extract 820
-PF PVDF Extract 820
-PK PEEK Extract 820
-SS Stainless Steel 1.4404 / 316L Extract 810
-HC Alloy C22 2.4602 Extract 810
Sealing Material -EPD EPDM
(wetted sealings) -FPM FPM (Viton)
-FKM FFKM (Kalrez)
Sensor -225 Suitable for 225mm PG13.5 Gel-filled
-280 Suitable for 280mm PG13.5 Liquid-filled
Process Connection -D32 Flange DN32 PN16 SS/Hast only
-D40 Flange DN40 PN16 SS/Hast only
-D50 Flange DN50 PN16
-A14 Flange ANSI 1 1 /
4
” 150lbs SS/Hast only
-A12 Flange ANSI 1 1 /
2
” 150lbs SS/Hast only
-A20 Flange ANSI 2” 150lbs
-N14 NPT M 1 1 /
4
”
-T20 Tri Clamp 2” SS/Hast only
Cleaning Connection -G18 G 1 /
8
” thread female
-G14 G 1 /
4
” thread female
-N14 1 /
4
” NPT female
Position switch -PN Pneumatic
Spareparts
Partnumber Description
10/2-123-40-001 Sealing Set EPDM
10/2-123-41-001 Sealing Set FPM
10/2-123-42-001 Sealing Set FFKM (Kalrez)
10/2-075-03-001 Drive Unit - sensor 225/325 pneum. position switch
10/2-075-03-002 Drive Unit - sensor 280/380 pneum. position switch
10/2-061-33-004 Insertion rod RF20H (Extract 810 and 820) 1.4404 / 316L
10/2-061-34-004 Insertion rod RF20H (Extract 810 and 820) 2.4602 / Alloy C22
10/2-061-22-004 Insertion rod RF20H (Extract 810 and 820) PP
10/2-061-23-004 Insertion rod RF20H (Extract 810 and 820) PVDF/Alloy C22
10/2-061-29-004 Insertion rod RF20H (Extract 810 and 820) PEEK
10/2-086-32-001 Set blind plug G
1 /
8
” 1.4301/316 for cleaning chamber
