Yokogawa 415 Steam and Gas - Manual (Page 56)

SELECT
(FLOW PARAMETERS)
FLOW INPUT TYPE
(FREQUENCY, ANALOG)
FLOW SIGNAL TYPE
(LINEAR, NON-LINEAR)
FLOW SIGNAL TYPE
(DIFFERENTIAL, VOLUMETRIC)
K-FACTOR
XXXXX.XXX
UP TO 10
FREQUENCIES &
K-FACTORS
CAN BE
ENTERED
FLOW CORRECTION
(LINEAR, SQUARE ROOT, NON-LINEAR)
NO SENSORS
(2, 1)
UP TO 20 INPUT
& OUTPUT
POINTS CAN BE
PROGRAMMED
FLOW SPAN 1
(MASS, VOLUME)
FLOW SPAN 1
(MASS, VOLUME)
LOW SPAN (at 20mA)
XXXX
SPAN (at 20mA)
XXXX
SPAN (at 20mA)
XXXX
CUTOFF (Low)
XX.X%
FLOW CUTOFF
XX.X%
FLOW CUTOFF
XX.X%
HIGH SPAN (at 20mA)
XXXX
1
For Steam measurement, the Span defaults to mass.
54 Calibration
