15 Watlow Silver Series OIT Installation Guide
2. Set the OIT in the panel cutout and hold it in place until all
clamps are in position.
3. Tighten the screw clamps in an even pattern until all are
uniformly snug.
Caution: Do not over-tighten the screws beyond snugness or
you may damage the housing or warp the overlay.
REINSTALLATION:
If, at any time, you are required to reinstall an OIT into a panel, be
aware that the gasket will take a ‘set’ to the panel and may no longer
provide an adequate NEMA 4 seal. Therefore, for best results, we
recommend that you replace the gasket if reinstallation is required.
Configuration Wiring
To configure the OIT using the EZwarePlus software, you will need an
Ethernet cable.
Ethernet
If using a switch or router between the PC and the OIT, use a straight-
through or crossover cable as required by the switch or router.
0600-0101-0000 Rev A
