Watlow Silver Series EM - Manual

Watlow Silver Series EM
Installation Guide
Introduction
Thank you for purchasing a Silver Series EM graphic operator interface
terminal (OIT) from Watlow. The Silver Series EM OITs are configured
using the EZwarePlus software (available separately from Watlow) and
include the following models:
Watlow P/N Maple Systems P/N
4.3” display TS00-0043-EM00 HMI5043L
7.0” display TS00-0070-EM00 HMI5070L
10” display TS00-0100-EM00 HMI5100L
This booklet describes the steps necessary for installing the Silver Series
EM OITs.
Applications Assistance
This manual is designed to provide the necessary in formation for
trouble-free installation and operation of your new Operator Interface
Terminal (OIT). However, if you need assistance, please call Watlow at
(507) 494-5656 between 7 a.m. and 5 p.m. Central Standard Time (CST).
Ask for an Applications Engineer. Or you may e-mail your questions to
[email protected].
For information on programming and configuring the OIT, please refer
to the EZwarePlus Programming Manual available from Watlow.
0600-0101-0000 Rev A
