Avaya 10U100 User Manual
Page 6
5
11
12
13
14
15
16
17
18
Talk/Hangup Button
Flash Button
Memory (Mem) Button
12 Button Keypad
Dual Function Receive
Volume Control
Antenna
Ringer ON/OFF Switch
Rechargeable Battery
and Belt Clip
22
23
24
25
In-Use Indicator Light (Talk)
Battery Charge Indicator Light
Remote Charging Well
Page Button
Base (Front)
19
20
21
10U100 Base
Headset Holder/Antenna
Power Indicator Light
Base (Underside)
26
27
28
29
30
31
32
32
AC Adapter Jack
AC Adapter Plug
AC Adapter
Telephone Wall Jack
Telephone Line Cord
Telephone Jack
Cord Retainer Clip
Pulse/Tone Switch
Refer to page 18 for
instructions on
Volume Control.
