10
Wiring
• To avoid an electric shock, when connecting the FP’s power cord terminals to the power ter-
minal block, confirm that the FP’s power supply is completely turned OFF, via a breaker, or
similar unit.
• To avoid the dangers of fire, electric hazards and equipment damage, be sure to use only the
specified voltage when operating the FP.
• Since there is no power switch on the FP unit, be sure to attach a breaker-type switch to its
power cord.
„ Electrical Specification
„ Environmental Specification
„ Power Cord Specifications
Use copper conductors only.
Item Specification
Pow
e
r Supply
Rated Voltage AC100V ~ AC240V
Allowable Voltage AC85V ~ AC264V
Rated Frequency 50 / 60HZ
Allowable Frequency
Range
40Hz - 72Hz
Allowable Voltage Drop 1 cycle (Max.) (Voltage drop interval must be 1s or more.)
Current Consumption
AC100V 1.1A or less (TYP 0.75A)
AC240V 0.7A or less (TYP 0.44A)
In-Rush Current 60A (Max.)
Voltage Endurance
AC1500V 20mA for 1 minute
(between charging and FG terminals)
Insulation Resistance
DC500V 10M
Ω (Min.)
(between charging and FG terminals)
Item Specification
Surrounding Air Temperature 0 ~ 50ºC (The panel should not incline more than 30º)
Storage Temperature -20 ~ +60ºC
Ambient Humidity 10 ~ 90%RH
(No condensation, Wet bulb temperature: 39ºC max.)
Storage Humidity
Air Purity (Dust)
0.1mg/m
3
(Max.) (No electrically conductive dust is
allowed)
Pollution Degree For use in Pollution Degree 2 environment
Power Cord Diameter 0.75mm
2
to 2.5mm
2
(18AWG to 12 AWG)
Conductor Type Simple or Twisted Wire
*1
Conductor Length
10mm [0.39 in.]
