C2000
Operation
‚ 8
Figure 3: Display Layout
The LEDs above each of the pump select keys are the status
indicators for that particular pump/fueling position. The green
LED on the left indicates call/in use. The red LED on the right
indicates collect/stopped. Table 3, below, shows the various states
these LEDs represent for each pump/fueling position.
GREEN LED
RED LED
STATUS
Fast Flash
—
Call for service
On Solid
—
Authorized
—
Slow Flash
Collect "A" Sale
—
On Solid
Pump Stopped
Fast Flash and
Fast Flash
Drive-Away
Slow Flash and
Slow Flash
Collect "A" and "B" Sales
Table 3: LED Indicators for Pump/Fueling Positions
