www.reelcraft.com

Series RT Spring Driven Hose Reels

Item

#

Description

#

Req. RT402-OLP RT403-OLP RT405-OLP RT406-OLP RT602-OLP RT603-OLP RT605-OLP RT802-OLP RT803-OLP RT805-OLP

1

1/4-20 Lock Nut

2

261650-1

261650-1

261650-1

261650-1

261650-1

261650-1

261650-1

261650-1

261650-1

261650-1

3

Spool Assembly

1

S600827

S600827

S600860

602239

S600827

S600827

S600828

S600879

S600879

602011

4

U-Bolt

1

3-117440

3-117440

3-117440

3-117440

3-117440

3-117440

3-117440

3-117440

3-117440

3-117440

5

Latch Pawl Assembly

1

S600823

S600823

S600823

S600823

S600823

S600823

S600823

S600823

S600823

S600823

6

Guide Arm Assembly

1

S600825

S600825

S600825

S600825

S600825

S600825

S600826

S600826

S600826

602014

7

Nut 1/2”

1

S76-108

S76-108

S76-108

S76-108

S76-108

S76-108

S76-108

S76-108

S76-108

S76-108

8

Hose Bumper

1

None

None

None

None

None

None

None

None

None

None

9

Hose Assembly

1

None

None

None

None

None

None

None

None

None

None

10 Nut 5/16”

4

261650-2

261650-2

261650-2

261650-2

261650-2

261650-2

261650-2

261650-2

261650-2

261650-2

11 Base Assembly

1

600824

600824

600824

600824

600824

600824

600833

600833

600833

602012

12 Spacing Washer

1

300034

300034

300034

300034

300034

300034

300034

300034

300034

300034

13 Snap Ring

1

300031

300031

300031

300031

300031

300031

300031

300031

300031

300031

14 Swivel Assembly

1

S600886

S600886

S600886

S600886

S600886

S600886

S600886

600914

600914

600914

“E” Dimensions - See page 1

5 3/4”

5 3/4”

5 3/4”

5 3/4”

5 3/4”

5 3/4”

6 1/4”

6 1/4”

6 1/4”

7 3/4”

Item

#

Description

#

Req. RT425-OLP RT435-OLP RT450-OLP RT465-OLP RT625-OLP RT635-OLP RT650-OLP RT825-OLP RT835-OLP RT850-OLP

1

1/4-20 Lock Nut

2

261650-1

261650-1

261650-1

261650-1

261650-1

261650-1

261650-1

261650-1

261650-1

261650-1

3

Spool Assembly

1

S600827

S600827

S600860

602239

S600827

S600827

S600828

S600879

S600879

602011

4

U-Bolt

1

3-117440

3-117440

3-117440

3-117440

3-117440

3-117440

3-117440

3-117440

3-117440

3-117440

5

Latch Pawl Assembly

1

S600823

S600823

S600823

S600823

S600823

S600823

S600823

S600823

S600823

S600823

6

Guide Arm Assembly

1

S600825

S600825

S600825

S600825

S600825

S600825

S600826

S600826

S600826

602014

7

Nut 1/2”

1

S76-108

S76-108

S76-108

S76-108

S76-108

S76-108

S76-108

S76-108

S76-108

S76-108

8

Hose Bumper

1

A1-HR1004-A A1-HR1004-A A1-HR1004-A A1-HR1004-A A1-HR1004

A1-HR1004

A1-HR1004 A2-HR1004-3 A2-HR1004-3 A2-HR1004-3

9

Hose Assembly

1

601001-25 601001-35 601001-50 601000-65 601013-25 601013-35 601013-50 601020-25 601022-35 601022-50

10 Nut 5/16”

4

261650-2

261650-2

261650-2

261650-2

261650-2

261650-2

261650-2

261650-2

261650-2

261650-2

11 Base Assembly

1

600824

600824

600824

600824

600824

600824

600833

600833

600833

602012

12 Spacing Washer

1

300034

300034

300034

300034

300034

300034

300034

300034

300034

300034

13 Snap Ring

1

300031

300031

300031

300031

300031

300031

300031

300031

300031

300031

14 Swivel Assembly

1

S600886

S600886

S600886

S600886

S600886

S600886

S600886

600914

600914

600914

“E” Dimensions - See page 1

5 3/4”

5 3/4”

5 3/4”

5 3/4”

5 3/4”

5 3/4”

6 1/4”

6 1/4”

6 1/4”

7 3/4”
