Owner’s Manual MMK-KVM8
Modular KVM Switch for
LCD Console Use
1.3 Technical Specifications
Feature Specification
KVM Type PS/2 and USB interface KVM switch
Console Ports Plus One Optional Remote Module
PC Port Connector HDDB-15
PC Ports 8
Max. Distance (KVM switch -- Host) 10 m (32 feet)
Video Resolution 1920 x 1440 (Local Console)
1280 x 1024 for IP-Based remote console
IP-Based Remote Module (MMK-IPM) RJ-45 8P8C for 10/100M Ethernet, DB9 male for Modem, Null
modem and serial power control, Mini USB 2.0 receptacle
Daisy Chaining Support Daisy Chaining with both Bus (8-layer) and Tree (2-layer)
topologies, DB15 Female Connector
Computer port selection On Screen Display (OSD) Menu, Hot Key
Hotkey Provide various Hotkey (Scroll-Lock/ Cap-Lock/ Num-Lock/ Alt/
Ctrl/ Win)
Security Provide ACL (Access Control List) security function, store up to 8
independent controllable Computer lists
Multilingual OSD (On Screen Display) control 8 languages (English, France, Germen, Spanish, Italian, Russian,
Japanese, Simplified Chinese)
Auto-Scan Intervals 5 ~ 99 Sec.
Keyboard Emulation PS/2 or USB
Mouse Emulation PS/2 or USB
Housing Metal
Power DC Power adapter : 12VDC, 1A
Operation Temperature 0° c – 50° c
Storage Temperature -20° c – 60° c
Humidity 0 – 80%, Non-Condensing
Mechanical For 1RU Rack Mount Modular Design LCD Console Use
Dimension 16.5" x 6.7" x 1.7" (420mm x 170mm x 44 mm)
Table 1-2. Technical Specifications
1.4 System Requirements
Model 8-port modular KVM switch
Computer Side 8 HDDB-15 pin male to one HDDB-15 pin, one Mini Din 6 pin,
and one USB special cables
IP Module One CAT5 cable, Network Access Environment
Table 1-3. System Requirements
