Ramsey Winch ATV-2500 - Manual (Page 11)

ATV2500 (Wireless Remote) Parts List
ITEM
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
PART
NO.
251214
251212
251191
251192
251193
251213
251236
251195
251196
251197
282058
251190
251234
251235
251198
257522
DESCRIPTION
MOTOR KIT
MOTOR END GEAR SET KIT
CLUTCH KIT
CABLE DRUM KIT
CABLE & HOOK KIT
CLUTCH END GEAR KIT
ROLLER FAIRLEAD KIT
BUSHING KIT
TIE BAR KIT
ELECTRICAL WIRING KIT
WIRELESS RECEIVER & TRANSMITTER KIT
WIRELESS TRANSMITTER KIT
SOLENOID KIT
TOGGLE SWITCH KIT
ANTENNA KIT
HARDWARE KIT*
Wireless Remote Control
Operation
Refer to page 6 of Wireless Remote Control
Installation Instructions for remote operation
notes. Refer to pages 2-4 of Installation
Instructions for instructions for installing the sole-
noid, receiver, antenna, and toggle switch.
C
AUTION
: W
HEN THE TRANSMITTER REACHES A
TEMPERATURE BELOW
0°F (-18°C)
IT WILL NOT
OPERATE
. I
N EXTREMELY COLD TEMPERATURES
,
KEEP
TRANSMITTER IN A POCKET OF INNERMOST LAYER OF
CLOTHING WHEN NOT IN USE
.
The transmitter has push buttons labeled accord-
ing to their function. Make sure the motor has
stopped fully before reversing to prevent prema-
ture solenoid failure. To operate the winch hold
“ON/OFF” button for 2 seconds to activate the
“IN” and “OUT” functions. Run winch forward and
reverse to check connection and to verify winch
operating directions. The transmitter is clearly
labeled and a red LED flashes when the winch is
in operation. Pushing both buttons at the same
time will not damage your winch in any way.
Press and hold the “ON/OFF” button on the trans-
mitter to disable the transmitter when winch is not
in use. This will prolong the battery life of the
transmitter. The transmitter automatically turns off
after 20 minutes.
*Hardware Kit
Item
No. Qty. Description
16-1 4 5/16-18UNC x 1” Hx Hd
Z/P GR5 Capscrew
16-2 2 3/8-16UNC x 3/4” Hx Hd
Z/P GR5 Capscrew
16-3 2 #10-24UNC x 3/4” Truss
Cross-recess F/B Capscrew
16-4 2 3/8-16UNC Hx GR2 Z/P Nut
16-5 2 #10-24UNC Hx Locknut
16-6 4 5/16 Med Z/P Lockwasher
16-7 2 3/8 Med Z/P Lockwasher
16-8 2 #10 Flat Washer Z/P
16-9 1 Wire Splice
16-10 2 Tube Clamp
16-11 12 Cable Ties (1 bag)
