Programming
F232226 10
To Edit an Entire Wash Cycle
Formula
Enter Program Mode. Refer to Entering Program
Mode. Press the ∧ keypad until display shows
“CY01”.
Select the cycle by pressing the desired cycle number.
Press START keypad to edit the cycle.
Agitation for the Cycle
With display showing “CYXX” (xx = cycle number),
press the START keypad. Display shows “AG1”,
“AG2”, “AG3” or “AG4”. Refer to Table 2 for a
description on Agitation.
Wash 1 – Wash 5
NOTE: Programming a time other than “00” for
Wash 1 will make the WASH indicator LED light
while this step is running, but NOT in Program
Mode.
The main display shows “USH1” indicating you are in
the Wash segment (number will reflect selected Wash
segment 1-5). Press START keypad. Display shows
agitation time during the step: “00” (skips segment) or
2-30 minutes. This is the time after the fill and before
the drain and does not include spin time or time to first
reach a programmed temperature (if your machine is
configured for heat). Press the ∧ or ∨ keypad to alter
the selection, or the START keypad to continue.
Display shows “CFIL”, “HFIL”, “bFIL” (for cold, hot,
or warm [both]) or “AFIL”. Press the ∧ or ∨ keypad
to alter the selection, or the START keypad to
continue.
NOTE: Auxiliary Fill (“AFIL”) possible only if
configured for “AFIL” in Setup Mode. If
configured, auxiliary fills can be programmed to
low, medium or high water level in a cycle step.
Display shows “LO”, “
n
Ed”, or “HI” for low, medium,
or high water level, respectively. Press the ∧ or ∨
keypad to alter the selection, or the START keypad to
continue.
Display shows “SUP0”, “SUP1”, “SUP2”, “SUP3”,
“SUP4”, “SUP5”, “SUP6”, or “SUP7” indicating no
supply, supply 1, supply 2, supply 3, supply 4, supply
5 (supply 1 and supply 2 together), supply 6, or supply
7 (supply 3 and supply 4 together). Press the ∧ or
∨ keypad to alter the selection, or the START keypad
to continue.
NOTE: “SUP5” and “SUP6” appear ONLY if
control is configured for “SUP5” (spare mode set
up to operate as an EXTRA supply signal for
external chemical) in Setup Mode. If the alternate
function for the spare output is selected (“AFIL”),
the output will function as an additional fill valve
signal with a programmable water level. In this
case, extra supply function would NOT be
available.
NOTE: If programmed for “SUP2”, the ADD
BLEACH indicator LED light turns on and the
buzzer sounds while supply 2 is on.
Press the ( ∧) or (∨) key to alter the selection or
START key to continue.
The washer-extractor has 5 supply compartments,
designated as compartments 1, 2, 3, 4 and 5.
Compartment 1 is farthest to the rear of machine.
Moving toward the front of machine, compartments
are ordered 2, 3, 4 and 5 (at the front of machine).
Supply signals 1 through 5 correspond to
compartments 1 through 5. Supply signals 1, 2, and 3
have dedicated water valves that flush compartments
1, 2 and 3 (along with the signal being available for
external supplies). Supply signal 4 operates a valve
that flushes compartment 4. The supply signal is
available for external supply connection. This valve is
connected so that it also flushes supply compartment 5
when the supply 4 signal is on. For example, if supply
4 signal is programmed, it will flush compartments 4
and 5. Supply 5 is available to operate an external
supply.
NOTE: For additional assistance, refer to
Installation Instructions.
Display Meaning
AG1 18 seconds forward, 3 seconds pause, 18
seconds reverse, 3 seconds pause and repeat
for the programmed time
AG2 3 seconds forward, 27 seconds pause, 3
seconds reverse, 27 seconds pause and repeat
for the programmed time
AG3 10 seconds forward, 20 seconds pause, 10
seconds reverse, 20 seconds pause and repeat
for the programmed time
AG4 4 seconds forward, 56 seconds pause, 4
seconds reverse, 56 seconds pause and repeat
for the programmed time
Table 4
