Lincoln Electric IM10171 WIRE FEED MODULE - Manual (Page 35)

1A Nameplate (Classic 300 HE) M24602 1 X
1B Nameplate (SAE 300 HE) M24693 1 X
2 Control Panel Wiring Harness, Includes: L9246-1 1 X
2A Potentiometer T10812-119 1 X
2B Connector S12021-70 1 X
2C Switch (S1 & S2) T10800-14 2 X
3A Rheostat Control Knob T10491 1 X
3C Potentiometer Spacer S18280 1 X
4 Self Tapping Screw S8025-96 4 X
6 Cap-Cable Connector S17062-11 1 X
8 Shaft Seal T14034 1 X
9 Spacer T7028-241 1 X
10A Fastener Button T14659-2 5 X
10B Self Tapping Screw S8025-92 5 X
Jan-2014 WIRE FEED MODULE
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-751-D.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-751-D.1
