Lincoln Electric IM10171 WIRE FEED MODULE User Manual
Page 31
1
Welded Frame Assembly
NSS
1
X
2A
P.C. Board Assembly
G2563-[ ]
1
X
2B
Plastic Expansion Nut (Not Shown)
S14020-3
4
X
2C
Thread Forming Screw
S8025-97
4
X
3A
Front Cover
S20879
1
X
3B
Thread Forming Screw
S9225-51
7
X
3C
Door Bumper
T14882-1
6
X
4A
Contactor (CR3)
M12161-33
1
X
4B
#10-24 x 50 RHS
CF000047
3
X
4C
Lock Washer
T9695-1
3
X
4D
#10-24 HN
CF000010
3
X
5A
Contactor Assembly (CR4)
M17198
1
X
5B
Contactor Mounting Bracket
S20650
1
X
5C
#10-32 x .25 RHS
CF000325
4
X
5D
Lock Washer
T9695-1
4
X
5E
Self Tapping Screw
S8025-91
4
X
Shunt & Lead Assembly, Includes:
S19588-1
1
X
6A
Uncalibrated Shunt
NSS
1
X
6B
Plug & Lead Assembly, (Not Shown)
NSS
1
X
6C
Sems Screw
T10082-4
2
X
6D
#10-24 HN
CF000010
2
X
6E
3/8-16 x .75 HHCS
CF000034
1
X
6F
Plain Washer
S9262-4
1
X
6G Lock Washer
E106A-16
1
X
6H
3/8-16 HJN
CF000121
1
X
7A
Resistor
S10404-129
1
X
7B
Resistor Mounting Bracket Set
T15137-2
1
X
7C
#8-32 x .50 RHS
CF000033
2
X
7D
Plain Washer (Not Shown)
S9262-3
2
X
7E
Lock Washer
T4291-A
2
X
7F
#8-32 HN
CF000042
2
X
Capacitor Bank Assembly, Includes:
M17233
1
X
8A
Capacitor
S13409-105
3
X
8B
Capacitor Buss
S18292-2
2
X
8C
Plain Washer
S9262-23
6
X
8D
Lock Washer
E106A-2
6
X
8E
1/4-28 x .50 HHCS (Part of 8A)
NSS
1
X
Capacitor Strap Assembly, Includes:
S20930
1
X
8F
Capacitor Strap
NSS
1
X
8H
Capacitor Insulation
S20947
1
X
8J
Self Tapping Screw
S8025-91
2
X
9A
Protection Insulation
S21199
1
X
9B
Self Tapping Screw
S8025-70
6
X
9C
Plain Washer
S9262-27
1
X
10
Power Cable Assembly
S20878
1
X
11A Thermostat Assembly
T14829-3
1
X
11B 5/16-18 x .75 HHCS
CF000040
1
X
11C Plain Washer (Not Shown)
S9262-121
1
X
11D Lock Washer (Not Shown)
E106A-14
1
X
11E 5/16-18 HN (Not Shown)
CF000029
1
X
12
Insulation S24067
1
X
Jan-2014
WIRE FEED MODULE
Use only the parts marked “x” in the column under the
heading number called for in the model index page.
# Indicates a change this printing.
P-751-C.1
ITEM DESCRIPTION
PART NO.
QTY.
1 2 3 4 5 6 7 8 9
P-751-C.1
NSS - Not Sold Separately
