A-2
INSTALLATION WIRE FEED MODULE™
ASSEMBLE INTO ENGINE DRIVEN WELDERS:
CLASSIC ® 300HE K3198-1
SAE-300 ® HE K3201-1, K3202-1
Pre Installation
Unpack WFM and check the contents against the listed items.
Tools Required
• Large and Small Flat Head Screwdriver
• Pliers
• 3/32” Allen Wrench
• 3/8” Drive Ratchet with Small Extension
• 1/2” Socket
• 9/16” Deep Well Socket
• 3/4” Socket
• 5/16” Nut Driver and Socket
• 1/2” Open End Wrench
• 9/16” Open End Wrench
• Voltmeter
ITEM DESCRIPTION QTY.
1 Control Module Assembly 1
2 Panel Components and Harness Assembly 1
3 Mounting Hardware Packet 1
4 Instruction Manual and Literature 1
5 Classic ® 300HE Nameplate 1
6 SAE-300 ® HE Nameplate 1
