Lincoln Electric IM10122 SAE400 - Manual (Page 40)

25 Filter Assembly (Not Shown) M17494-2 1 X
Water Separator Element (Not Shown) M21584-B 1 X
M8 x 1.25 Metric HHCS T14731-4 2 X
Plain Washer S9262-121 2 X
Lock Washer E106A-3 2 X
26 Temperature Switch/Sender S25162 1 X
28 Oil Filler Spacer (Not Shown) S25992 1 X
M8 x 1.25 SHCS T14731-3 2 X
Gasket S26001 1 X
Lock Washer E106A-24 2 X
30 Amp to Lucar Adapter S26426 1 X
04-03-2012
SAE-400 ®
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-692-D.2
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-692-D.2
