A-1 INSTALLATION
SAE-400®
A-1
TECHNICAL SPECIFICATIONS - SAE-400® (K1278-14)
Make/Model Description Speed (RPM) Displacement Starting Capacities
System
269 cu. in Fuel: 22.5 gal.
(4.4 L) 85.1 L
K1278-14
Perkins
1104A-44 Diesel
4 cylinder High Idle 1800 Bore x Stroke 12VDC battery Oil: 10.1 Qts.
Engine 64.4 HP @ Low Idle 1100 & Starter 9.6 L
Not EPA Tier II 1710 RPM Full Load 1725
Compliant 4.13” x 5.00”
Export Only (105.0 mm x 127.0mm) Coolant: 3.4 gal.
12.8 L
INPUT - DIESEL ENGINE
RATED OUTPUT - WELDER
HEIGHT WIDTH DEPTH WEIGHT
50.13 in. 28.00 in. 83.00 in. 2157lbs.
1273.3 mm 711.2 mm 2108.2 mm 978.4kg
OUTPUT - WELDER AND GENERATOR
Duty Cycle (1) Welding Output Volts at Rated Amps
35% (NEMA) 500 amps 40 volts
* 60% (NEMA) 500 amps 40 volts
100% (NEMA) 400 amps 36 volts
100% (Lincoln Plus) 400 amps 40 volts
Welding Range Open Circuit Voltage Auxiliary Power
80 - 575 Amps 97 Max. OCV 115/230 VAC
@ 1800 RPM 3000 Watts, 60 Hz.
100% Duty Cycle
PHYSICAL DIMENSIONS
(1) Based on a 10 minute period.
*
For Codes 11807 and higher.
RECEPTACLES AUXILIARY POWER CIRCUIT BREAKER
1 - 115VAC Duplex NEMA (5-20R)-GFCI protected 1 - 20 amp for 115VAC Duplex NEMA
1 - 115VAC European (IEC-309)-GFCI protected 1 - 15 amp for 115VAC European (IEC-309)
1 - 230VAC Duplex 1 - 15 amp (2 -pole) for 230 V Duplex and European (IEC-309)
1 - 230VAC European (IEC-309)
RECEPTACLES AND CIRCUIT BREAKERS
