AUPS IEI Technology Corp.
- 9 -
Read Smart Battery Status (Command : 0x41 ),and return 2 bytes
High byte：
Return byte Name Description
Bit 0 TEMPOVER_A If 1 = Battery A is not charging , temperature > 60 ºC
Bit 1 TEMPOVER_B If 1 = Battery B is not charging, temperature > 60 ºC
Bit 2 TEMPGOVER_A If 1 = Battery A is charging, temperature > 45 ºC
Bit 3 TEMPGOVER_B If 1 = Battery B is charging, temperature > 45 ºC
Bit 4 VOLOW_A If 1 = Battery A Output Voltage < normal rated voltage
Bit 5 VOLOW_B If 1 = Battery B Output Voltage < normal rated voltage
Bit 6 VOLOVER_A If 1 = Battery A Output Voltage > normal rated voltage
Bit 7 VOLOVER_B If 1 = Battery B Output Voltage > normal rated voltage
Low byte：
Return byte Name Description
Bit 0 BATTERYFULL_A If 1 = Battery A Full
Bit 1 BATTERYFULL_B If 1 = Battery B Full
Bit 2 BATA_CHGF If 1 = Battery A is charging
Bit 3 BATB_CHGF If 1 = Battery B is charging
Bit 4 BATA_STANDBY If 1 = Battery A is standby
Bit 5 BATB_STANDBY If 1 = Battery B is standby
Bit 6 BATA_USE If 1 = Battery A is discharging
Bit 7 BATB_USE If 1 = Battery B is discharging
