AUPS IEI Technology Corp.
- 8 -
Read Smart Battery Alarm (Command : 0x40 ),and return 2 bytes
High byte：
Return byte Name Description
Bit 0 ADIN_ACTF If 1 = DC Power is connected to AUPS module
Bit 1 BUZZER_ACTF If 1 = Buzzer is enabled
Bit 2 UPSONOFF_ACTF If 1 = UPS output is turned on
Bit 3 LAN_ACTF If 1 = LAN is enabled
Bit 4 BATB_ACTF If 1 = Battery B is connected
Bit 5 BATA_ACTF If 1 = Battery A is connected
Bit 6 None Don’t Care
Bit 7 None Don’t Care
Low byte：
Return byte Name Description
Bit 0 BATA3_ACTF If 1 = Battery A type is 3 packs in serial
Bit 1 BATB3_ACTF If 1 = Battery B type is 3 packs in serial
Bit 2 BATA4_ACTF If 1 = Battery A type is 4 packs in serial
Bit 3 BATB4_ACTF If 1 = Battery B type is 4 packs in serial
Bit 4 BATA2_ACTF If 1 = Battery A type is 2 packs in serial
Bit 5 BATB2_ACTF If 1 = Battery B type is 2 packs in serial
Bit 6 SOFT_OFF If 1 =window OS is Shut Down
Bit 7 None Don’t Care
Note: None : Read as ‘0’
