AFOLUX LX Panel PC
Page 18
Feature
AMD Geode™ LX Processor
Bresenham Lines
Yes
Patterned (stippled) Lines
Yes
Screen to Screen BLT
Yes
Screen to Screen BLT with mono expansion
Yes
Memory to Screen BLT
Yes (throttled rep movs writes)
Accelerated Text
No
Pattern Size (Mono)
8x8 pixels
Pattern Size (Color)
8x8 pixels
Monochrome Pattern
Yes (with inversion)
Dithered Pattern (4 color)
No
Color Pattern
8, 16, 32 bpp
Transparent Pattern
Monochrome
Solid Fill
Yes
Pattern Fill
Yes
Transparent Source
Monochrome
Color Key Source Transparency
Y with mask
Variable Source Stride
Yes
Variable Destination Stride
Yes
Destination Write Bursting
Yes
Selectable BLT Direction
Vertical and Horizontal
Alpha BLT
Yes (constant α, α/pix, or sep. α channel)
VGA Support
Decodes VGA Register
Pipeline Depth
Unlimited
Accelerated Rotation BLT
8, 16, 32 bpp
Color Depth Conversion
5:6:5, 1:5:5:5, 4:4:4:4, 8:8:8:8
Table 2-1: Geode LX Graphics Features
