AFL-xxA-N270 Series Panel PC
Page 3
802.11 b/g wireless module
Two USB 2.0 ports
Watchdog timer that triggers a system reset if the system hangs for some
reason
IP 64 compliant front panel
AT or ATX power mode
Touch screen
Bluetooth
RoHS compliance
There are four kinds of panel size of the AFL-xxA-N270 series. The model numbers and
model variations are listed below.
Model Size Brightness Resolution
AFL-07A-N270/WT-R/1GB 7” 350 cd/m 2 WVGA (800 x 480)
AFL-08AH-N270/WT-R/1GB 8.4” 450 cd/m 2 SVGA (800 x 600)
AFL-10A-N270/WT-R/1GB 10.4” 400 cd/m 2 SVGA (800 x 600)
AFL-12A-N270/WT-R/1GB 12.1” 400 cd/m 2 XGA (1024 x 768)
Table 1-1: Model Variations
1.1.2 Applications
The AFL-xxA-N270 panel PCs are elegant yet sophisticated systems that are easily
implemented in commercial environments, industrial environments and corporate
environments.
1.2 External Overview
1.2.1 General Description
The stylish AFL-xxA-N270 panel PC comprises of a screen, rear panel, top panel, bottom
panel and two side panels (left and right). An ABS/PC plastic front frame surrounds the
front screen. The rear panel provides screw holes for a wall-mounting bracket compliant
with VESA FDMI standard. An I/O interface panel on the bottom panel of the
