AFL-xxA-N270 Series Panel PC
Page 134
Manufacturing Technology 45 nm
L1 Cache
32 KB instruction cache
24 KB write-back data cache
Thermal Design Power 2.5 W
Tjunction 0 to 90°C
A.3 Screen Specifications
The AFL-xxA-N270 comes with a TFT LCD monitor at the front of the flat panel PC.
Specifications for the screens are shown below.
SPECIFICATION AFL-07A-N270 AFL-08AH-N270 AFL-10A-N270 AFL-12A-N270
Model DATA IMAGE
FG0700A1DSCWBGL1
AUO-G084SN05 Toshiba
LTA104D182F
Toshiba
PI-LTA121C250F
Size 7” 8.4” 10.4” 12.1”
Resolution 800 x 480 (VGA) 800 x 600 (SVGA) 800 x 600 (SVGA) 1024 x 768 (XGA)
Active Area (mm) 152.4 x 91.44 170.4 x 127.8 211.2 x 158.4 245.76 x 184.32
Pixel Pitch (mm) 0.1905 x 0.1905 0.213 x 0.213 0.264 x 0.264 0.240 x 0.240
LCD Color Native 262K colors Native 262K colors Native 262K colors Native 262K colors
View Angel (H/V) 140/100 140/120 120/100 120/100
Brightness (cd/m 2 ) 350 450 400 400
Contrast Ratio 400:1 600:1 500:1 500:1
Response Time (ms) 15(Tr) / 20(Tf) 10(Tr) / 25(Tf) 6(Tr) / 17(Tf) 10(Tr) /30(Tf)
Supply Voltage (V) 3.3 3.3 3.3 3.3
Backlight 1 CCFL 2 CCFL 2 CCFL 2 CCFL
Backlight MTBF (hrs.) 50000 50000 50000 60000
Dimensions (mm) 165.0 x 104.0 x 5.5 203.0 x 142.5 x 8.0 242.0 x 178.45 x 3.2 278.3 x 209.0 x 12.0
