NANO-9453 EPIC Motherboard
Page 34
Connector Type Label
Front panel connector 8-pin header F_PANEL1
IDE Interface connector 44-pin header IDE1
Infrared connector 5-pin header IR1
Inverter power connector 5-pin header INVERTER1
LVDS connector 30-pin crimp LVDS1
Parallel port connector 26-pin header LPT1
PCI-104 slot 104-pin slot PC104_PLUS1
PCIe Mini Card slot 52-pin slot CN4
Serial ATA (SATA) connector 7-pin SATA connector SATA1
Serial ATA (SATA) connector 7-pin SATA connector SATA2
Serial port connectors (Four RS-232 ports) 40-pin header COM
Serial port connector (RS-422/485) 4-pin wafer connector CN5
USB connector 8-pin header USB01
USB connector 8-pin header USB23
Table 4-1: Peripheral Interface Connectors
4.1.3 External Interface Panel Connectors
Table 4-2 lists the rear panel connectors on the NANO-9453. Detailed descriptions of
these connectors can be found in Section 4.3 on page 58
Connector Type Label
Ethernet connector RJ-45 LAN1
Ethernet connector RJ-45 LAN2
Keyboard and mouse connector PS/2 connector KB_MS1
