NANO-9453 EPIC Motherboard
Page 6
Specification NANO-9453
Southbridge: Intel
®
ICH7M
Memory
One 200-pin SO-DIMM socket supports one 533MHz or
667MHz DDR2 SO-DIMM with a maximum capacity of 1GB
Display
Dual VGA: Integrated in the Intel
®
945GM to support CRT
LVDS: Dual channel 18-bit LVDS LCD panel
BIOS AMI BIOS
Audio 7.1 channel or 5.1 channel audio with an optional AC-KIT
LAN Two Broadcom PCIe GbE controllers
COM
Three RS-232 internal serial ports
One RS-232, RS-422 or RS-485 serial port
USB2.0 Six USB 2.0 devices supported
IDE One 44-pin IDE connects to two Ultra ATA33/66/100 devices
SATA Two 3.0Gb/s SATA drives supported
Keyboard/mouse
One PS/2 connector supports mouse and keyboard
connectivity
Watchdog Timer Software programmable 1-255 sec. by super I/O
Power Supply 12V only, AT and ATX supported
Temperature 0ºC – 60ºC (32ºF - 140ºF)
Humidity (operating) 5%~95% non-condensing
Dimensions (LxW) 165mm x 115mm
Weight (GW/NW) 800g/ 260g
Table 1-1: Technical Specifications
