KINO-945GSE Motherboard
Page 61
PIN DESCRIPTION PIN DESCRIPTION
1 L_KDAT 7 L_MDAT
2 NC 8 NC
3 GND 9 GND
4 5 V 10 5 V
5 L_KCLK 11 L_MCLK
6 NC 12 NC
Table 4-20: PS/2 Connector Pinouts
4.3.3 DVI Connector
CN Label: VIDEO1 (bottom)
CN Type: DVI connector
CN Location: See Figure 4-20
CN Pinouts: See Figure 4-22 and Table 4-21
Connects to a monitor that supports DVI video input.
PIN Signal Name Pin Signal Name Pin Signal Name
1 TMDS Data2- 9 TMDS Data1- 17 TMDS Data0-
2 TMDS Data2+ 10 TMDS Data1+ 18 TMDS Data0+
3 GND 11 GND 19 GND
4 N/C 12 NC 20 NC
5 N/C 13 NC 21 NC
6 DDC Clock [SCL] 14 PVDD1 22 GND
7 DDC Data [SDA] 15 GND 23 TMDS Clock +
8 Analog vertical sync 16 HPDET 24 TMDS Clock -
Table 4-21: DVI Connector Pinouts
4.3.4 LAN Connectors
CN Label: LAN/USB1 & LAN/USB2
CN Type: RJ-45
CN Location: See
7
Figure 4-20
