KINO-945GSE Motherboard
Page 40
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 +3.3 V 11 +3.3 V
2 +3.3 V 12 -12 V
3 GND 13 GND
4 +5 V 14 PS-ON
5 GND 15 GND
6 +5 V 16 GND
7 GND 17 GND
8 PW-OK 18 -5 V
9 +VCC5SB 19 +5 V
10 +12 V 20 +5 V
Table 4-3: ATX Power Connector Pinouts
4.2.2 Battery Connector
CN Label: BT1
CN Type: 2-pin wafer (1x2)
CN Location: See Figure 4-4
CN Pinouts: See Table 4-4
The battery connector is connected to a backup battery. The battery connector is also
used to reset the CMOS memory if the incorrect BIOS settings have been made and the
system cannot boot up.
