2 internal peripheral interface connectors – IEI Integration KINO-945GSE v1.10 User Manual
Page 53
KINO-945GSE Motherboard
Page 37
Figure 4-2: Connector and Jumper Locations [Back Side]
4.1.2 Internal Peripheral Interface Connectors
Table 4-1 shows a list of the peripheral interface connectors on the KINO-945GSE.
Detailed descriptions of these connectors can be found below.
Connector
Type
Label
ATX power connector
20-pin power connector
PWR1
Battery connector
2-pin box header
BT1
CompactFlash® slot
CompactFlash® slot
J2
DDR2 SO-DIMM slot
SO-DIMM connector
DIMM1
Digital I/O connector
10-pin header
DIO1
