KINO-945GSE Motherboard
Page 38
Connector Type Label
Fan connector 3-pin wafer J1
Front panel connector 14-pin header F_PANEL1
IDE connector 44-pin box header IDE1
Infrared connector 5-pin header IR1
LCD backlight inverter connector 5-pin box header INVERTER1
LVDS connector 30-pin crimp LVDS1
PCIe Mini slot PCIe Mini connector MINI_PCIE1
RS-232 connector 10-pin header COM3
RS-232 connector 10-pin header COM4
RS-422/485 connector (COM3) 6-pin header JP2
SATA connector SATA port SATA1
SATA connector SATA port SATA2
SPI flash connector 6-pin SPI1
TV output connector 6-pin header TV1
USB connector (2 ports) 8-pin header USB1
Table 4-1: Peripheral Interface Connectors
4.1.3 External Interface Panel Connectors
7
Table 4-2 lists the rear panel connectors on the KINO-945GSE. Detailed descriptions of
these connectors can be found in Section 77
7
4.3 on page
7
59.
Connector Type Label
Audio connector Dual audio jack AUDIO1
DVI / VGA combo connector VGA and
DVI connector
VIDEO1
LAN / USB combo connector LAN and
2 x USB
LAN/USB1
LAN/USB2
PS/2 keyboard / mouse connector 2 x PS/2 KBMS1
