SPCIE-C2160 PICMG 1.3 CPU Card

Page 9

Specification/Model

SPCIE-C2160

Front Panel

One 14-pin header (power LED, HDD LED, speaker, power button,

reset button)

I2C

One 4-pin wafer connector

Infrared

One via 5-pin header

Keyboard/Mouse

One 6-pin wafer connector

Parallel Port

One parallel port via internal 26-pin box header

Serial ATA

Four SATA 3Gb/s connectors (support RAID 0, 1, 5, 10)

Two SATA 6Gb/s connectors (support RAID 0, 1, 5, 10)

Serial Ports

Four RS-232 via internal box headers

One RS-422/485 via internal 4-pin wafer connector

SMBus

One 4-pin wafer connector

TPM

One via 20-pin header

USB Ports

Two external USB 2.0 ports on rear IO

Six internal USB 2.0 ports by three pin headers

Environmental and Power Specifications

Power Supply

AT/ATX power supported

Power Consumption

[email protected] , [email protected], [email protected], [email protected],

[email protected] (3.4 GHz Intel® Xeon® E3 CPU with two 2GB 1333 MHz

DDR3 memory)

Operating

Temperature

-10ºC ~ 60ºC

Storage

Temperature

-20ºC ~ 70ºC

Humidity

5% ~ 95% (non-condensing)

Physical Specifications

Dimensions

338 mm x 126 mm

Weight (GW/NW)

1200 g / 420 g

Table 1-2: SPCIE-C2160 Specifications
