SPCIE-C2160 PICMG 1.3 CPU Card

Page 86

Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.

Advanced

Smart Fan Mode Configuration

CPU_FAN1 Smart Fan Control

[Auto Duty-Cycle Mode]

CPU Temperature 1

60

CPU Temperature 2

50

CPU Temperature 3

40

CPU Temperature 4

30


Smart Fan Mode Select


---------------------

ÆÅ: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General

Help

F2: Previous

Values

F3: Optimized

Defaults

F4: Save & Exit
ESC: Exit

Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.

BIOS Menu 17: Smart Fan Mode Configuration

Î CPU_FAN1 Smart Fan Control [Auto Duty-Cycle Mode]

Use the CPU_FAN1 Smart Fan Control option to configure the CPU Smart Fan.

Î

Auto

Duty-Cycle

Mode

D

EFAULT

The fan adjusts its speed using Auto Duty-Cycle

Mode settings

Î

Manual Duty

Mode

The fan spins at the speed set in Manual Duty

Mode settings

Î CPU Temperature n

Use the +/– key or enter a decimal number to change the CPU Temperature n value.

5.3.11 Serial Port Console Redirection

The Serial Port Console Redirection menu (BIOS Menu 18) allows the console

redirection options to be configured. Console redirection allows users to maintain a

system remotely by re-directing keyboard input and text output through the serial port.
