SPCIE-C2160 PICMG 1.3 CPU Card
Page 3
1.2 Model Variations
The model variations of the SPCIE-C2160 are listed below.
Model No. CPU Supported DVI-D by 26-pin header
SPCIE-C2160-DVI-R10 LGA1155 Intel® Xeon® E3/
Core™ i3/Pentium®/Celeron®
Yes
SPCIE-C2160-R10 LGA1155 Intel® Xeon® E3/
Core™ i3/Pentium®/Celeron®
No
Table 1-1: SPCIE-C2160 Model Variations
1.3 Features
Some of the SPCIE-C2160 motherboard features are listed below:
ƒ PICMG 1.3 full-size graphics grade solution
ƒ LGA1155 CPU socket
ƒ Intel® C216 chipset
ƒ Dual-channel DDR3 DIMMs support up to 16.0 GB
ƒ Dual independent display by VGA and DVI-D (DVI model only)
ƒ One PCIe Mini expansion slot
ƒ Two Intel® PCIe Gigabit Ethernet connectors (LAN2 with Intel® AMT 8.0
support)
ƒ Two SATA 6Gb/s connectors with RAID function
ƒ Four SATA 3Gb/s connectors with RAID function
ƒ TPM V1.2 hardware security function supported by the TPM module
ƒ High Definition Audio
ƒ RoHS compliant
