Use the default setting unless it is clearly inappropriate. Any changes to this setting remain in
effect until either the setting is changed or 10 seconds after the R Series unit is turned off
(returning the setting to its default).
As a safety feature, the cuff can never be inflated to more than 300 mmHg (40.0 kPa) in adult or
pediatric mode, and 150 mmHg (20.0 kPa) in neonatal mode.
Setting Cuff Inflation Pressure
Before taking a measurement, check that the cuff inflation pressure is appropriate for the
patient. The cuff inflation pressure options are:
See the R Series Configuration Guide for information on reconfiguring the cuff inflation
pressure default setting.
WARNING!
Do not set cuff inflation pressure too high, particularly for neonatal, pediatric, or frail
patients. Serious injury can result.
To set the cuff inflation pressure:
1. Press the Settings softkey, then the Cuff Inflation softkey from the NIBP menu. If the
Cuff Inflation softkey is not displayed, see “Displaying the NIBP Menu” on page 10.
The R Series unit displays the Cuff Inflation menu:
2.
Press the Next softkey if “Inflation Pressure” is not highlighted.
3.
Press the Inc or the Dec softkey to select cuff inflation pressure.
4.
Press the Return softkey to return to the NIBP menu.
The cuff inflation pressure is set.
Adult
Pediatric
Neonatal
120 mmHg (16.0 kPa)
80 mmHg (10.7 kPa)
60 mmHg (8.0 kPa)
140 mmHg (18.7 kPa)
90 mmHg (12.0 kPa)
70 mmHg (9.3 kPa)
160 mmHg (21.3 kPa)
100 mmHg (13.3 kPa)
80 mmHg (10.7 kPa)
180 mmHg (24.0 kPa)
110 mmHg (14.7 kPa)
90 mmHg (12.0 kPa)
200 mmHg (26.7 kPa)
120 mmHg (16.0 kPa)
100 mmHg (13.3 kPa)
220 mmHg (29.3 kPa)
130 mmHg (17.3 kPa)
110 mmHg (14.7 kPa)
240 mmHg (32.0 kPa)
140 mmHg (18.7 kPa)
120 mmHg (16.0 kPa)
260 mmHg (34.7 kPa)
150 mmHg (20.0 kPa)
130 mmHg (17.3 kPa)
Return
Inc
Dec
Prev
Next
Auto Adjust
On
Adult Inflation Pressure
160 mmHg
