P
AGE
35 800.444.3595 I 516.921.0538 fax I www.winholt.com
T
RANSPORT
& M
OBILE
S
TORA
GE
Dolly Galvanized
This Stack and Nest Dolly is constructed of all welded
galvanized steel.
Maneuvers easily on two 5" rubber swivel plate casters
and two 5" rigid plate casters.
Designed for a long life of rugged use, the Stack and
Nest Container improves efficiency and productivity.
The uniform thickness and design gives maximum
strength and protection to your goods. Built-in rim
handles and a polyethylene material makes this product
easy to handle.
USDA approved material.
Option:
Stack & Nest Container & Lids.........See chart below
Model
Number
Ordering
Number
Overall Dimensions Approx.
Ship Wt Width Length Height
(in) (mm) (in) (mm) (in) (mm) (lb) (kg)
Lug – Gray Polyethylene
SN-2618 104424 19 476 26 667 11 267 7 3
Lid – Gray Polyethylene
LID-2618 104416 19 476 27 686 1 25 2 0.9
Dolly – Galvanized Steel
DSN-2618 102074 18 457 26 660 6 152 19 9
Caster Information
7317 123043 Swivel Plate Caster with 3" Rubber Wheel ⎯
749 123561 Rigid Plate Caster with 3" Rubber Wheel ⎯
Multi-Purpose Handling
System!
Can be used for
Sheet Pans or
Stack & Nest Containers.
G
OOD
M
EDIUM
D
UTY U SE
Equipment Guide
DSN-2618
Freight Class: 100
Aluminum Sani Stock Cart
Heavy Duty
Ideal cart for universal applications in all departments.
T-Bar Shelves provide extra strength and allow for ease
of product sliding on and off.
All welded, sanitary, aluminum design. Uprights and
handles are secured in place by heavy duty, welded
collars.
Easily maneuverable on two 5” swivel plate and two rigid
plate polyurethane casters.
Model
Number
Ordering
Number
Overall Dimensions
Capacity
Approx.
Ship Wt Width Length Height
(in) (mm) (in) (mm) (in) (mm) (lb) (kg) (lb) (kg)
TBST-1837 137411 18 457 39 991 37 940 300 136 30 14
Caster Information
738ABK 209185 Swivel Plate Caster with 5” Poly Wheel & Brake ⎯
743A 127892 Rigid Plate Caster with 5” Poly Wheel ⎯
7112 122180 5” Polyurethane Wheel ⎯
B
ETTER
M
EDIUM
D
UTY U SE
L IFE W ARRANTY
A GAINST R UST
Equipment Guide
Freight Class: 250
