WARN PullzAll SERVICE GUIDE 885005 & 885006 User Manual
Page 23

987606A1.doc
Page 23 of 46
8. Support one edge of the Wire and pull the
other Wire as shown in the figure.
9. Verify Wire Rope stop button is inserted
into the loop as shown before pulling the
Wire Rope tight.
10. Hit wire rope loop with a hammer, so that
the Wire Rope will be pushed in to the
rope retention hole.
