Product Introduction:
Thank you for purchasing a yard ramp from Vestil Manufacturing Corporation. Our ramps are rigorously
engineered for durability, quality, and safety. Specifications for each yard ramp variant appear in the following table:
AY-167230 16,000 (~7,273kg) 74 (188cm) 66 (167.6cm) 30 (9.1m) 2783 (1265kg)
AY-168430 16,000 (~7,273kg) 86 (218.4cm) 78 (198.1cm) 30 (9.1m) 3150 (1431.8kg)
AY-169330 16,000 (~7,273kg) 95 (241.3cm) 87 (221cm) 30 (9.1m) 3465 (1575kg)
AY-167236-L 16,000 (~7,273kg) 74 (188cm) 66 (167.6cm) 36 (11m) 3360 (1527.3kg)
AY-168436-L 16,000 (~7,273kg) 86 (218.4cm) 78 (198.1cm) 36 (11m) 3728 (1694.5kg)
Model Uniform Capacity in
Pounds (~kg) Overall Width in
Inches (~cm) Usable Width in
Inches (~cm) Length in Feet
(~m) Net Weight in
Pounds (~kg)
YR-16-7230 16,000 (~7,273kg) 72 (183cm) 67 (170.2cm) 30 (9.1m) 3780 (1718kg)
YR-16-8430 16,000 (~7,273kg) 84 (213.4cm) 78 (198.1cm) 30 (9.1m) 4095 (1861.4kg)
YR-16-7236 16,000 (~7,273kg) 72 (183cm) 67 (170.2cm) 36 (11m) 4725 (2147.7kg)
YR-16-8436 16,000 (~7,273kg) 84 (213.4cm) 78 (198.1cm) 36 (11m) 5040 (2291kg)
YR-20-7230 20,000 (~9,091kg) 73 (185.4cm) 67 (170.2cm) 30 (9.1m) 4515 (2052.3kg)
YR-20-8530 20,000 (~9,091kg) 85 (216cm) 78 (198.1cm) 30 (9.1m) 4830 (2195.5kg)
YR-20-7336 20,000 (~9,091kg) 73 (185.4cm) 67 (170.2cm) 36 (11m) 5565 (2529.5kg)
YR-20-8536 20,000 (~9,091kg) 85 (216cm) 78 (198.1cm) 36 (11m) 5985 (2720.5kg)
YR-25-7330 25,000 (~11,364kg) 73 (185.4cm) 67 (170.2cm) 30 (9.1m) 4725 (2147.7kg)
YR-25-8530 25,000 (~11,364kg) 85 (216cm) 78 (198.1cm) 30 (9.1m) 5040 (2290.9kg)
YR-25-7336 25,000 (~11,364kg) 73 (185.4cm) 67 (170.2cm) 36 (11m) 5880 (2672.7kg)
YR-25-8536 25,000 (~11,364kg) 85 (216cm) 78 (198.1cm) 36 (11m) 6300 (2863.6kg)
YR-30-7330 30,000 (~13,636kg) 73 (185.4cm) 67 (170.2cm) 30 (9.1m) 4935 (2243.2kg)
YR-30-8530 30,000 (~13,636kg) 85 (216cm) 78 (198.1cm) 30 (9.1m) 5250 (2386.4kg)
YR-30-7336 30,000 (~13,636kg) 73 (185.4cm) 67 (170.2cm) 36 (11m) 6300 (2863.6kg)
YR-30-8536 30,000 (~13,636kg) 85 (216cm) 78 (198.1cm) 36 (11m) 6720 (3054.5kg)
YRD-16-7236-H 16,000 (~7,273kg) 72 (183cm) 66 (167.6cm) 36 (11m) 5670 (2577.3kg)
YRD-16-8436-H 16,000 (~7,273kg) 84 (213.4cm) 78 (198.1cm) 36 (11m) 6090 (2768.2kg)
YRD-20-7336-H 20,000 (~9,091kg) 73 (185.4cm) 66 (167.6cm) 36 (11m) 5880 (2672.7kg)
YRD-20-8536-H 20,000 (~9,091kg) 85 (216cm) 78 (198.1cm) 36 (11m) 6300 (2863.6kg)
YRD-25-7336-H 25,000 (~11,364kg) 73 (185.4cm) 66 (167.6cm) 36 (11m) 6090 (2768.2kg)
YRD-25-8536-H 25,000 (~11,364kg) 85 (216cm) 78 (198.1cm) 36 (11m) 6510 (2959.1kg)
YRD-30-7336-H 30,000 (~13,636kg) 73 (185.4cm) 66 (167.6cm) 36 (11m) 6300 (2863.6kg)
YRD-30-8536-H 30,000 (~13,636kg) 85 (216cm) 78 (198.1cm) 36 (11m) 6720 (3054.5kg)
YRDS-16-7236-M 16,000 (~7,273kg) 72 (183cm) 66 (167.6cm) 36 (11m) 5905 (2684.1kg)
YRDS-16-8536-M 16,000 (~7,273kg) 85 (216cm) 78 (198.1cm) 36 (11m) 6325 (2875kg)
YRDS-20-8536-M 20,000 (~9,091kg) 85 (216cm) 78 (198.1cm) 36 (11m) 6535 (2970.5kg)
YRDS-16-7236-H 16,000 (~7,273kg) 72 (183cm) 66 (167.6cm) 36 (11m) 5890 (2677.3kg)
YRDS-16-8536-H 16,000 (~7,273kg) 85 (216cm) 78 (198.1cm) 36 (11m) 6310 (2868.2kg)
YRDS-20-8536-H 20,000 (~9,091kg) 85 (216cm) 78 (198.1cm) 36 (11m) 6520 (2963.6kg)
Aluminum yard ramps with steel grating
SY-167230 16,000 (~7,273kg) 74 (188cm) 66 (167.6cm) 30 (9.1m) 3518 (1599.1kg)
SY-168430 16,000 (~7,273kg) 86 (218.4cm) 78 (198.1cm) 30 (9.1m) 4043 (1837.7kg)
SY-169330 16,000 (~7,273kg) 95 (241.3cm) 87 (221cm) 30 (9.1m) 4515 (2052.3kg)
SY-167236-L 16,000 (~7,273kg) 74 (188cm) 66 (167.6cm) 36 (11m) 4305 (1956.8kg)
SY-168436-L 16,000 (~7,273kg) 86 (218.4cm) 78 (198.1cm) 36 (11m) 4830 (2195.5kg)
SY-169336-L 16,000 (~7,273kg) 95 (241.3cm) 87 (221cm) 36 (11m) 5303 (2410.5kg)
SY-207230 20,000 (~9,091kg) 74 (188cm) 66 (167.6cm) 30 (9.1m) 3623 (1646.8kg)
SY-208430 20,000 (~9,091kg) 86 (218.4cm) 78 (198.1cm) 30 (9.1m) 4148 (1885.5kg)
SY-209330 20,000 (~9,091kg) 95 (241.3cm) 87 (221cm) 30 (9.1m) 4620 (2100kg)
SY-207236-L 20,000 (~9,091kg) 74 (188cm) 66 (167.6cm) 36 (11m) 4410 (2004.5kg)
SY-208436-L 20,000 (~9,091kg) 86 (218.4cm) 78 (198.1cm) 36 (11m) 4935 (2243.2kg)
SY-209336-L 20,000 (~9,091kg) 95 (241.3cm) 87 (221cm) 36 (11m) 5408 (2458.2kg)
SY-257230 25,000 (~11,364kg) 74 (188cm) 66 (167.6cm) 30 (9.1m) 3675 (1670.5kg)
SY-258430 25,000 (~11,364kg) 86 (218.4cm) 78 (198.1cm) 30 (9.1m) 4200 (1909.1kg)
SY-259330 25,000 (~11,364kg) 95 (241.3cm) 87 (221cm) 30 (9.1m) 4725 (2147.7kg)
SY-257236-L 25,000 (~11,364kg) 74 (188cm) 66 (167.6cm) 36 (11m) 4463 (2028.6kg)
SY-258436-L 25,000 (~11,364kg) 86 (218.4cm) 78 (198.1cm) 36 (11m) 4988 (2267.3kg)
SY-259336-L 25,000 (~11,364kg) 95 (241.3cm) 87 (221cm) 36 (11m) 5513 (2505.9kg)
SY-307230 30,000 (~13,636kg) 74 (188cm) 66 (167.6cm) 30 (9.1m) 3728 (1694.5kg)
SY-308430 30,000 (~13,636kg) 86 (218.4cm) 78 (198.1cm) 30 (9.1m) 4253 (1933.2kg)
SY-307236-L 30,000 (~13,636kg) 74 (188cm) 66 (167.6cm) 36 (11m) 4515 (2052.3kg)
SY-308436-L 30,000 (~13,636kg) 86 (218.4cm) 78 (198.1cm) 36 (11m) 5040 (2290.9kg)
Aluminum yard ramps with aluminum grating
