4
HEAVY DUTY PANEL CART • MODEL PRCT-HD
Assembly & Parts Drawing
PARTS IDENTIFICATION
HEAVY DUTY PANEL CART • MODEL PRCT-HD
WARNING LABEL IDENTIFICATION
MAKE SURE ALL WARNING LABELS ARE IN PLACE!
* Product safety signs or labels should be periodically inspected and cleaned by
the product users as necessary to maintain good legibility for safe viewing
distance. ANSI 535.4 (10.21) Contact manufacturer for replacement labels.
1
1
2
3
4
CASTER PAD
BRACKET
5
6
6a
ITEM NO.
1
2
3
4
5
6
6a
A
B
C
DESCRIPTION
Handle
Bolt, 3/8"-16 UNC x 1" (HHCS)
Nylock nut, 3/8"-16 UNC
Wheel, (rigid caster)
Wheel, (swivel caster w/ brake)
Clevis pin, 3/8"x 5"
Cotter pin, 3/8"
Bolt Kit (includes 2,3,6,7)
Handle Kit (includes 1-3)
Wheel Kit (includes 4-7)
ENGINEER NO.
16-514-083
a/k
a/k
16-132-029
16-132-127
99-112-006
n/a
16-154-003
16-154-008
16-154-009
QTY.
3
18
18
2
2
4
4
1
1
1
KIT NO.
B
A,B
A,B
C
C
A,C
A,C
*Item 6 and 6a are sold together
a/k
Available only with purchase of kit
PART NO.
PCHD-HDL
a/k
a/k
PCHD-CASR
PCHD-CASB
n/a
n/a
PCHD-KITA
PCHD-KITB
PCHD-KITC
