11
PARTS LIST
Valid for 1,000 lb. to 6,000 lb. capacities
ITEM NO.
1
2
3
4
5
6
7
8
9
10
N/S
11
DESCRIPTION
Guard, Left Side
Guard, Right Side
Hold-Down Tube, Outer
Hold-Down Spring
Hold-Down Tube, Inner
Chute Assembly
Hinge Block
Stop Block
Mounting Hardware
Cylinder Split Pin, Upper
Cylinder Screw, Lower
Cylinder Pin
QTY.
1
1
1
1
1
1
2
2
8
2
2
2
2,000 & 4,000 lb.
PART NO.
HBD-GL
HBD-GR
HBD-TO
HBD-SP
HBD-TI
HBD-CH
HBD-HB
HBD-SB
HBD-MH
HBD-CU
HBD-CS
HBD-CP
6,000 lb.
PART NO.
HBD-GL
HBD-GR
HBD-TO
HBD-SP
HBD-TI
HBD-CH
HBD-HB
HBD-SB
HBD-MH
HBD60-CU
N/A
HBD60-CP
