Vestil HBD series - Manual

1
Revised 03-03
A company dedicated to solving ergonomic and
material handling problems since 1955.
Contents
Warnings and Safety Instructions ................... 1
Receiving Instructions .................................... 1
Installation Instructions ................................... 2
Routine Maintenance Instructions .................. 2
Operation Instructions .................................... 3
Power Unit Operation .................................. 4-5
Air Bleed Instructions ..................................... 5
Motor and Transformer Diagram ..................... 6
WARNINGS & SAFETY INSTRUCTIONS
Ensure that all employees understand and follow the
following instructions!!!
• Read and understand the owner's manual before using or
servicing the dumper.
• The load must be removed from the chute and the chute
fully lowered before any work is performed on the lift.
• Ensure that all safety and warning labels stay in place and
are legible. See the label page in this manual.
• The dumper's frame must be securely anchored to the floor.
See the installation instructions.
• Do not use the dumper if any damage or unusual noise is
observed.
• Always watch the chute and the barrel carefully when the
dumper in operation.
• Do not perform any modifications to the dumper without the
manufacturer's approval. Failure to receive authorization
for changes to the equipment could void the warranty.
• Maintenance and repairs are to be done only by personnel
qualified to perform the required work.
• Do not use brake fluid or jack oils in the hydraulic system.
If oil is needed, use an anti-wear hydraulic oil with a
viscosity grade of 150 SUS at 100°F, (ISO 32 cSt @ 40°C),
or Dexron transmission fluid.
• Use only replacement parts either supplied or approved by
the manufacturer.
RECEIVING INSTRUCTIONS
Every unit is thoroughly tested and inspected prior
to shipment. However, it is possible that the unit may incur
damage during transit. If you see damage when unloading,
make a note of it on the BILL OF LADING. HYDRAULIC BOX DUMPER
SERIES HBD
HYDRAULIC BOX DUMPER
series HBD
VESTIL MANUFACTURING CORPORATION
P.O. Box 507, Angola, IN 46703
Phone (260) 665-7586 • Fax (260) 665-1339
[email protected] • www.vestil.com
OWNER'S
MANUAL
Remove all packing and strapping material. Inspect
for damage. IF DAMAGE IS EVIDENT, FILE A CLAIM
WITH THE CARRIER IMMEDIATELY! Also, check the unit
size, type of power unit, etc., to ensure the dumper is cor-
rect for the intended application.
Electrical Schematic (1-4K) ........................... 7
Electrical Schematic (6K) .............................. 8
Hydraulic Schematic ..................................... 9
Exploded Parts Drawing ............................. 10
Parts List ............................................... 11-12
Troubleshooting Guide ................................ 13
Warning Label Identification ........................ 14
Limited Warranty ......................................... 15
