rev. 12/18/2012 ABLT-H, Manual
Bill of materials for FIG. 1
Item no. Part no. Description Quantity
1 1003370 Lower frame weldment 1
2 1003371 Upper frame weldment 1
3 12440 Scissor weldment inner 1,000 lbs to 3,000 lbs 1
4 12611 Scissor weldment outer 1,000 lbs to 3,000 lbs 1
3 + 4
combined
12967 Scissor weldment assembly 4,000 lbs 1
5 300-001 Air bag K-900 1
100-332 Hose ½ in. push to lok 144
1002551 Sticker Warning/Caution wrap 1
1001372 Sticker 1-800 black small 2
6
12175
12718
ABLT-H-2-32 & ABLT-H-3-32
Wheel assembly
ABLT-H-4-32
Wheel assembly
4
4
7 1002704 Small spacer 4
8 1002721 Large spacer 4
9 1002720 Washer step 8
10 85D Washer flat ½ in. SAE z-plated 4
11 500-122B Bolt hex ½ in. – 13 x 3in. grade 5 z-plated 2
12 1002123 Bolt hex ½ in. – 13 x 5in. grade 5 z-plated 4
13 84J ½ in. – 13 bi-way z-plated lock nut 6
14 1002731 Wheel stop block 4
15 83f Bolt hex ½ in. – 13 x 1in. grade 5 z-plated 8
16 85h ½ in. z-plated lock washer 8
17 1002123 Bolt hex ½ in. – 13 x 5 grade 5 z-plated bolt 1
18 1003586 ½ in. x ½ in. NPT barb ptl hose 3
19 008-368 Valve P3 pos2 2-way ½ in. NPT no pilot 1
20 008-367 ¾ in. silencer 1
21 1002504 Block 1½in. NPTM x ½ in. NPT x ½ NPT 1
100-332 Hose ½ in. push to lok 20
22 1000597 Washer case hard 2¼in. outer diameter x
5 /
8
in. inner diameter
2
23 1001259 ½ in. – 13 z-plated hex nut 4
24 1001881 ½ in. NPT x 40psi pressure relief valve 1
25 13834 Bolt storage bracket 1
1001146
1002788
1002296
1002050 Decal
ABLT-H-1-32: maximum capacity 1,000 lbs
ABLT-H-2-32: maximum capacity 2,000 lbs
ABLT-H-3-32: maximum capacity 3,000 lbs
ABLT-H-4-32: maximum capacity 4,000 lbs
2
2
2
2
