Accu-Trans

Operating Procedures
4
2.0 ACCU-TRANS SPECIFICATIONS
Table 1. ACCU-TRANS SPECIFICATIONS
TYPE Special-purpose test equipment, portable, micro-ohmmeter
SIZE (inches) 16.8 wide by 12.6 high by 10.6 deep
WEIGHT Less than 21 pounds
RESISTANCE 1 micro-ohm to 200 ohms
TEST CURRENT 2 amperes max
DISPLAY LCD, back-lighted, 4-line by 20-character
PRINTER 2.5-inch wide thermal printer
ACCURACY ± 1 % reading, ± 1 count
POWER 2 amps, 90-120 / 200-240 V ac (selectable), 50/60 Hz
SERIAL INTERFACE RS-232C connector port
ENVIRONMENT Operating: 0°C to 55°C; Storage: -40°C to 65°C
WARRANTY One-year parts & labor (post warranty service is available)
NOTE:
THE ABOVE SPECIFICATIONS ARE VALID AT NOMINAL OPERATING VOLTAGE AND AT A TEMPERATURE OF 25
°C (77°F)
?ACCU-TRANS
 SPECIFICATIONS MAY BE UPGRADED AND CHANGED WITHOUT PRIOR NOTICE.
