Accu-Trans

Operating Procedures
14
NOTE
To review a test record stored in Flash
EEPROM, the user must first restore test
record from Flash EEPROM to working
memory (see paragraph 6.3.3).
These procedural steps begin by selecting
SETUP on the Start-Up Menu, which
displays the Set-Up Menu, shown below:
a) In the Set-Up Menu (see above), press 2
to select the REVIEW RECORD procedure.
It starts with the display shown below. Go to
the next step.
b) Press 1 (SCROLL TEST RECORD) to
view all the test records in memory (see
menu above).
c) Press 2 (PRINT TEST RECORDS) to
output test record to the thermal printer.
See Fig. 5.0 for typical test record printout.
d) Pressing the 1 key (SCROLL TEST
RECORD) produces the RECORD “ID”
INFO display. This menu displays the
information related to the test.
e) To scroll through the test records in
memory, press the UP (
∧
) key to roll up or
press the down (
∨
) key to roll down, through
the saved test records.
The next menu displays the number of test.
in the record, time and date of the test.
There are 2 tests in the test record below.
f) Press the UP (
∧
) key to review the
resistance measured in the first test, which
show in the following display.
g) Press the UP (
∧
) key again to display the
second test on the record as shown below:
h) When the operator has reviewed the test
measurement for the selected record in the
display above, press STOP to return to the
Start-Up Menu. This ends the steps for
reviewing saved test records.
6.3.3 Restore Recording Procedures
This procedure allows the user to restore a
test record from the Accu-Trans Flash
EEPROM to working memory. The user can
then review the test record using the
REVIEW RECORD command (6.3.2).
The Restore Recording Procedure steps
begin at the Set-Up Menu, shown next:
1. ENTER XFMR ID
2. REVIEW RECORD
3. RESTORE RECORD
4. NEXT PAGE
REVIEW RECORD
1. SCROLL TEST RECORD
2. PRINT TEST RECORD
RECORD “ID” INFO:
2 TESTS
06/12/01 12:21:34
TEST NUMBER: 1
ACTIVE TEST
10.88 OHM
AT 0.824 Amps
TEST NUMBER: 2
ACTIVE TEST
122.8 MILLI-OHMs
AT 2.000 Amps
