Page 6
6
3xtend/EINC L/24 Installation Instructions TG200811 Issue 3 3/9/08
3xtend/EINC L/24
Installation Instructions
1 2 3 4 5 6 7 8 9 10
1.4
INSTALLATION - CONFIGURATION
Remove Covers
3
1 2 3 4 5 6 7 8 9 10
a
b
c
d
e
Fix Unit
1
Section 1.3
Switch off
2
O
I
1
Note that this product may involve
L
ON
W
ORKS
system integration. This
procedure should only be performed by
an installer with L
ON
W
ORKS
expertise.
!
ADDRESS
ON
Set Internetwork Address
(Lan number)
4
SET
NOT SET
e.g.
Address = 2 + 16 + 64 = 82
ON
= A
3xtend/EINC L
Lan
Lan
/
= A
Lan
/
= A
Lan
/
= A
If address < 100, INC Mode
If address = > 100, Internetwork Extension Mode
Address = A
address
1, 4 to 9, 11 to 119
0, 2, 3, 10 or >119
Internetwork
(on Ethernet)
Internetwork
(on L
ON
W
ORKS
)
3xtend/
EINC L
Lan
(on current loop)
Internetwork
(on Ethernet)
Internetwork
(on L
ON
W
ORKS
)
Internetwork
(on current loop)
Note that only one internetwork device is allowed on a Lan therefore ensure that the 3xtend/EINC L’s LAN number is not
used by another INC type device.
Note that it is recommended that the L
ON
W
ORKS
network is not used where a high level of communication traffic is expected,
e.g. joining internetworks or where there are many IQ System devices on many IQ System Lans being accessed across
an internetwork routed through the L
ON
W
ORKS
network. An alternative topology should be used, such as an Ethernet
internetwork.
3xtend/
EINC L
